Products Name:
TIFXP-1A Qualitative Leakage Detector

Overview
The TIFXP-1A is the culmination of more than 30 years of leakage detector manufacturing experience, and is a stable and sensitive negative corona leak detector.
The core of this device is an advanced microprocessor, of which digital signal processing makes it possible to manipulate the circuit and sensing head signals better than before. In addition, the number of components used in the circuit is reduced by about 40%, improving reliability and performance. The microprocessor monitors the sensing head and battery voltage value in real time, up to 4000 times per second, and can compensate for the signal pulsation even with the slightest fluctuation. This makes this instrument can be applied in almost any environment and become a stable and reliable detection tool.
Main Features
Microprocessor control with advanced digital signal processing
3-color, 6-section and 18-level alarm display
Noise suppression
Seven levels of sensitivity, providing up to 64 times the number
Cordless and portable, and operated with two C batteries
Touch keyboard control
Including carrying case
Real-time sensitivity adjustment
Technical Parameters
Sensitivity | ≮3 g/year (adjustable) |
Alarm mode | Sound, indicator lamp or sound-light |
Probe mode | Flexible probe |
Sampling mode | Diffusion-type |
Detection principle | DC negative corona discharge |
Load cycle | Continuous unlimited |
Warm-up time | About 2 seconds |
Power supply | DC 3V Two C alkaline batteries |
Battery life | Continuous use for about 40 hours when the battery is fully charged |
Chassis dimensions | 230mm×570mm×570mm |
Probe length | 355mm |
Weight | About 560g |
